Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
229
Format Mode Resolution Color mode Maximal S800 frame rates for Format_7 modes
7 0 1388 x 1038


1388 x 1038
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
15 fps

15 fps

15 fps
15 fps

15 fps

15 fps

15 fps

15 fps
1 692 x 1038 Mono8

Mono12

Mono16
15 fps 2x H-binning

15 fps 2x H-binning

15 fps 2x H-binning
2 1388 x 518 Mono8

Mono12

Mono16
26 fps 2x V-binning

26 fps 2x V-binning

26 fps 2x V-binning
3 692 x 518 Mono8

Mono12

Mono16
26 fps 2x H+V binning

26 fps 2x H+V binning

26 fps 2x H+V binning
4 692 x 1038


692 x 1038
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
15 fps 2 out of 4 H-sub-sampling

15 fps 2 out of 4 H-sub-sampling

15 fps 2 out of 4 H-sub-sampling
15 fps 2 out of 4 H-sub-sampling

15 fps 2 out of 4 H-sub-sampling

15 fps 2 out of 4 H-sub-sampling

15 fps 2 out of 4 H-sub-sampling

15 fps 2 out of 4 H-sub-sampling
5
# 1388 x 518


1388 x 518
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
15 fps 2 out of 4 V-sub-sampling

15 fps 2 out of 4 V-sub-sampling

15 fps 2 out of 4 V-sub-sampling
15 fps 2 out of 4 V-sub-sampling

15 fps 2 out of 4 V-sub-sampling

15 fps 2 out of 4 V-sub-sampling

15 fps 2 out of 4 V-sub-sampling

15 fps 2 out of 4 V-sub-sampling
6
# 692 x 518


692 x 518
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
15 fps 2 out of 4 H+V-sub-sampling

15 fps 2 out of 4 H+V-sub-sampling

15 fps 2 out of 4 H+V-sub-sampling
15 fps 2 out of 4 H+V-sub-sampling

15 fps 2 out of 4 H+V-sub-sampling

15 fps 2 out of 4 H+V-sub-sampling

15 fps 2 out of 4 H+V-sub-sampling

15 fps 2 out of 4 H+V sub-sampling
Table 87: Video Format_7 default modes Stingray F-146B / F-146C
