Configuration of the camera
STINGRAY Technical Manual V4.4.4
338
Reset of error codes
The ErrorCode field is set to zero on the next write access.
You may also reset the ErrorCode
•
by writing to the USER_PROFILE register with the SaveProfile, Resto-
reProfile and SetDefaultID flag not set.
•
by writing 00000000h to the USER_PROFILE register.
Stored settings
The following table shows the settings stored inside a profile:
The user can specify which user profile will be loaded upon startup of the
camera.
This frees the user software from having to restore camera settings, that dif-
fer from default, after every startup. This can be especially helpful if third
party software is used which may not give easy access to certain advanced
features or may not provide efficient commands for quick writing of data
blocks into the camera.
Standard registers
Standard registers
(Format_7)
Advanced registers
Cur_V_Frm_Rate
Cur_V_Mode
Cur_V_Format
ISO_Channel
ISO_Speed
BRIGHTNESS
AUTO_EXPOSURE (Target grey level)
SHARPNESS
WHITE_BALANCE (+ auto on/off)
HUE (+ hue on)
SATURATION (+ saturation on)
GAMMA (+ gamma on)
SHUTTER (+ auto on/off)
GAIN
TRIGGER_MODE
TRIGGER_POLARITY
TRIGGER_DELAY
ABS_GAIN
IMAGE_POSITION (AOI)
IMAGE_SIZE (AOI)
COLOR_CODING_ID
BYTES_PER_PACKET
TIMEBASE
EXTD_SHUTTER
IO_INP_CTRL
IO_OUTP_CTRL
IO_INTENA_DELAY
AUTOSHUTTER_CTRL
AUTOSHUTTER_LO
AUTOSHUTTER_HI
AUTOGAIN_CTRL
AUTOFNC_AOI (+ on/off)
COLOR_CORR (on/off + color correction
coefficients)
TRIGGER_DELAY
MIRROR_IMAGE
HIGH_SNR
LUT_CTRL (on/off + LUT + LutNo)
SHDG_CTRL (on/off + ShowImage)
DEFERRED_TRANS (HoldImg +
NumOfImages)
Table 168: User profile: stored settings
