Specifications
STINGRAY Technical Manual V4.4.4
46
Specifications
STINGRAY F-033B/C (fiber)
Note

• For information on bit/pixel and byte/pixel for each
color mode see
Table 104: ByteDepth on page 254.
• Maximum protrusion means the distance from lens
flange to the glass filter in the camera.
Feature Specification
Image device Type 1/2 (diag. 8 mm) progressive scan SONY IT CCD ICX414AL/AQ with
HAD microlens
Effective chip size 6.5 mm x 4.9 mm
Cell size 9.9 µm x 9.9 µm
Picture size (max.) 656 x 492 pixels (Format_7 Mode_0)
Lens mount C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)

maximum protrusion: 10.1 mm

(see Figure 36: Stingray C-Mount dimensions on page 85)
CS-Mount: 12.526 mm (in air), Ø 25.4 mm (32 tpi)

maximum protrusion: 5.1 mm

(see Figure 35: Stingray CS-Mount dimension on page 84)
Note: Maximum protrusion means the distance from lens flange to the
glass filter in the camera.
ADC 14 bit
Color modes Only color: Raw8, Raw12, Raw16, Mono8, YUV422, YUV411, RGB8
Frame rates 1.875 fps; 3.75 fps; 7.5 fps; 15 fps; 30 fps; 60 fps

Up to 84 fps in Format_7
Gain control Manual: 0-24.4 dB (0.0359 dB/step); auto gain (select. AOI)
Shutter speed 31 µs … 67,108,864 µs (~ 67 s); auto shutter (select. AOI)
External trigger shutter Programmable, trigger level control, single trigger,

bulk trigger, programmable trigger delay
Internal FIFO memory 32 MByte, up to 50 frames
Look-up tables User programmable (12 bit  10 bit); default gamma (0.45)
Table 11: Specification STINGRAY F-033B/C (fiber)
