Camera interfaces

STINGRAY Technical Manual V4.4.4

101

Outputs

Output features are configured by software. Any signal can be placed on any
output.

The main features of output signals are described below:

Note

Switching trigger delay to ON also switches external
Trigger_Mode_0 to ON.

This feature works with external Trigger_Mode_0 only.

Note

For a general description of the outputs and warnings see
the Hardware Installation Guide, Chapter STINGRAY out-
put description.

Signal

Description

IntEna (Integration Enable) signal

This signal displays the time in which exposure was made. By
using a register this output can be delayed by up to 1.05 sec-
onds.

Fval (Frame valid) signal

This feature signals readout from the sensor. This signal Fval
follows IntEna.

Busy signal

This signal appears when:

the exposure is being made or

the sensor is being read out or

data transmission is active.

The camera is busy.

PulseWidthMod (pulse-width modu-
lation) signal

Each output has pulse-width modulation (PWM) capabilities,
which can be used for motorized speed control or autofocus
control. See Chapter

Pulse-width modulation (Stingray housing

and Stingray board level models)

on page 106ff.

WaitingForTrigger signal

This signal is available and useful for the outputs in Trigger
Edge Mode
. (In level mode it is available but useless, because
exposure time is unknown. (Signal always =0))

In edge mode it is useful to know if the camera can accept a
new trigger (without overtriggering).

See

Table 29: Output routing

on page 104 and

Figure 47: Output

impulse diagram

on page 105

Table 27: Output signals
