Introduction

STINGRAY Technical Manual V4.4.4

23

continued from last page

V4.4.1

07.01.11

Minor corrections

Converted FrameMaker files from FM7 to FM9

Added required minimum number of GrabCount value (2)
for HIGH_SNR ON in

Table 151: Advanced register: High Sig-

nal Noise Ratio (HSNR)

on page 321

Added info that for 8-bit video modes, the internal HSNR
calculations are done with 14 bit: Chapter

High SNR mode

(High Signal Noise Ratio)

on page 168

Changed tripod drawing: added dimensions of three big
holes (M6 and UNC 1/4-20) in

Figure 25: Tripod dimensions

on page 74.

Added Windows 7 support and revised Windows XP/
Windows Vista in in Chapter

FireWire and operating

systems

on page 42

V4.4.2

15.04.11

Added sensitivity curves for Stingray F-125B/F-125C:

see

Figure 13: Spectral sensitivity of Stingray F-125B

on

page 66 and

see

Figure 14: Spectral sensitivity of Stingray F-125C

(without IR cut filter)

on page 66

C-/CS-Mount no more adjustable, for modifications contact
Customer Care and send camera to AVT:

See Chapter

Specifications

on page 46ff.

See Chapter

Adjustment of C-Mount and CS-Mount

on page

85.

Stingray firmware update round:

Defect pixel correction: you don’t need to set value for
brightness to max. any more: see

Figure 66: Defect pixel

correction: build and store

on page 142 and Chapter

Grab

an image with defect pixel data

on page 143

Besides in Mono8 mode defect pixel correction is also
possible in Raw8 mode: see note in Chapter

Building

defect pixel data

on page 143

Revised Chapter

Defect pixel correction

on page 140

Image is shot internally during calculating a mean value:
see note in Chapter

Calculate defect pixel coordinates

on

page 143

Activate HSNR mode to improve defect pixel correction:
see note in Chapter

Building defect pixel data

on page 143

Added descriptions for defect pixel correction in F7 modes:
see Chapter

Building defect pixel correction image in

Format_7 modes

on page 141

to be continued on next page

Version

Date

Remarks

Table 1: Document history
