Specifications
STINGRAY Technical Manual V4.4.4
48
STINGRAY F-046B/C (fiber)
Feature Specification
Image device Type 1/2 (diag. 8 mm) progressive scan SONY IT CCD ICX415AL/AQ with
HAD microlens
Effective chip size 6.5 mm x 4.8 mm
Cell size 8.3 µm x 8.3 µm
Picture size (max.) 780 x 580 pixels (Format_7 Mode_0)
Lens mount C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)

maximum protrusion: 10.1 mm

(see Figure 36: Stingray C-Mount dimensions on page 85)
CS-Mount: 12.526 mm (in air), Ø 25.4 mm (32 tpi)

maximum protrusion: 5.1 mm

(see Figure 35: Stingray CS-Mount dimension on page 84)
Note: Maximum protrusion means the distance from lens flange to the
glass filter in the camera.
ADC 14 bit
Color modes Only color: Raw8, Raw12, Raw16, Mono8, YUV422, YUV411, RGB8
Frame rates 1.875 fps; 3.75 fps; 7.5 fps; 15 fps; 30 fps; 60 fps

Up to 61 fps in Format_7
Gain control Manual: 0-24.4 dB (0.0359 dB/step); auto gain (select. AOI)
Shutter speed 31 µs … 67,108,864 µs (~ 67 s); auto shutter (select. AOI)
External trigger shutter Programmable, trigger level control, single trigger,

bulk trigger, programmable trigger delay
Internal FIFO memory 32 MByte, up to 35 frames
Look-up tables User programmable (12 bit  10 bit); default gamma (0.45)
Smart functions AGC (auto gain control), AEC (auto exposure control), real-time shad-
ing correction, LUT, 32 MByte image memory, mirror, binning (only

b/w), sub-sampling, High SNR, deferred image transport, SIS (secure
image signature), sequence mode, 4 storable user sets
Only color: AWB (auto white balance), color correction, hue, satura-
tion
Two configurable inputs, four configurable outputs
RS232 port (serial port, IIDC V1.31)
Transfer rate 100 Mbit/s, 200 Mbit/s, 400 Mbit/s, 800 Mbit/s
Table 12: Specification STINGRAY F-046B/C (fiber)
