Configuration of the camera
STINGRAY Technical Manual V4.4.4
318
Color correction
To switch off color correction in YUV mode: see bit [6]
For an explanation of the color correction matrix and for further information
read Chapter
Color correction on page 177.
Register Name Field Bit Description
0xF10003A0 COLOR_CORR Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..5] Reserved
ON_OFF [6] Color correction on/off
default: on
Write: 02000000h to switch
color correction OFF
Write: 00000000h to switch
color correction ON
Reset [7] Reset to defaults
--- [8..31] Reserved
0xF10003A4 COLOR_CORR_COEFFIC11 = Crr [0..31] A number of 1000 equals a
color correction coefficient
of 1.
Color correction values
range -1000..+2000 and are
signed 32 bit.
In order for white balance
to work properly ensure that
the row sum equals to 1000.
The maximum row sum is
limited to 2000.
0xF10003A8 COLOR_CORR_COEFFIC12 = Cgr [0..31]
0xF10003AC COLOR_CORR_COEFFIC13 = Cbr [0..31]
0xF10003B0 COLOR_CORR_COEFFIC21 = Crg [0..31]
0xF10003B4 COLOR_CORR_COEFFIC22 = Cgg [0..31]
0xF10003B8 COLOR_CORR_COEFFIC23 = Cbg [0..31]
0xF10003BC COLOR_CORR_COEFFIC31 = Crb [0..31]
0xF10003C0 COLOR_CORR_COEFFIC32 = Cgb [0..31]
0xF10003C4 COLOR_CORR_COEFFIC33 = Cbb [0..31]
0xF10003A4
...
0xF10003FC
Reserved for

testing purposes
Don’t touch!
Table 147: Advanced register: Color correction
