Introduction
STINGRAY Technical Manual V4.4.4
15
continued from last page
V2.2.0
[continued]
15.08.08
[continued]
[continued]
Rounded offsets in Chapter Exposure time (shutter) and offset
on page 194f. and in Figure 99: Data flow and timing after end
of exposure on page 199.
Added new image of Stingray camera with two screws on either
side of the cameras for fixing the front flange:
– See title page
New Stingray photo on title page (with new screws on either
side of camera)
New photo of LED positions in Figure 44: Position of status LEDs
on page 94
V2.3.0 12.09.08 New Stingray board level CAD drawing with new Molex 1.25 mm
Pitch PicoBlade Wire-to-Board Header (53047-1310) and new
cable lengths in
Figure 41: Board level camera: two IEEE 1394b
FireWire connectors on page 91 and in Figure 43: Board level
camera: I/O pin assignment on page 93
V2.4.0 30.09.08 New Stingray board level CAD drawing with new Molex 1.25 mm
Pitch PicoBlade Wire-to-Board Header (53047-1310) in:
– Figure 37: Stingray board level dimensions on page 86
– Figure 38: Stingray board level: CS-Mount on page 87
– Figure 39: Stingray board level: C-Mount on page 88
to be continued on next page
Version Date Remarks
Table 1: Document history
