STINGRAY F-504B/C (fiber)

Feature

Specification

Image device

Type 2/3 (diag. 11 mm) progressive scan SONY IT CCD ICX655ALA/AQA
with Super HAD microlens

Effective chip size

8.5 mm x 7.1 mm

Cell size

3.45 µm x 3.45 µm

Picture size (max.)

2452 x 2056 pixels (Format_7 Mode_0)

Lens mount

C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)

maximum protrusion: 10.1 mm

(see

Figure 36: Stingray C-Mount dimensions

on page 85)

CS-Mount: 12.526 mm (in air), Ø 25.4 mm (32 tpi)

maximum protrusion: 5.1 mm

(see

Figure 35: Stingray CS-Mount dimension

on page 84)

Note: Maximum protrusion means the distance from lens flange to the
glass filter in the camera.

ADC

14 bit

Color modes

Only color: Raw8, Raw12, Raw16, Mono8, YUV422, YUV411, RGB8

Frame rates

1.875 fps; 3.75 fps; 7.5 fps; 15 fps

Up to 9 fps in Format_7

Gain control

Manual: 0 ... 24.053

dB (0.0359

dB/step); auto gain (select. AOI)

Shutter speed

42 µs … 67,108,864 µs (~ 67 s); auto shutter (select. AOI)

External trigger shutter

Programmable, trigger level control, single trigger,

bulk trigger, programmable trigger delay

Internal FIFO memory

64 MByte, up to 5 frames

Look-up tables

User programmable (12 bit  10 bit); default gamma (0.45)

Smart functions

AGC (auto gain control), AEC (auto exposure control), real-time shad-
ing correction, LUT, 64 MByte image memory, mirror, binning (b/w and
color models), sub-sampling, High SNR, deferred image transport, SIS
(secure image signature), sequence mode, 4 storable user sets

only color: AWB (auto white balance), color correction, hue, satura-
tion, sharpness

Two configurable inputs, four configurable outputs

RS232 port (serial port, IIDC V1.31)

Transfer rate

100 Mbit/s, 200 Mbit/s, 400 Mbit/s, 800 Mbit/s

Table 18: Specification STINGRAY F-504B/C (fiber)
