Configuration of the camera
STINGRAY Technical Manual V4.4.4
328
Example
To map the internal Format_7 Mode_19 to the visible Format_7 Mode_1,
write the decimal number 19 to the above listed F7MODE_1 register.
Low noise binning mode (2 x and 4 x binning)
This register enables/disables low noise binning mode.
This means: an average (and not a sum) of the luminance values is calculated
within the FPGA.
The image is therefore darker than with the usual binning mode, but the sig-
nal to noise ratio is better (approximately a factor of
).
Note

For available Format_7 modes see Figure 87: Mapping of
possible Format_7 modes to F7M1...F7M7 on page 160.
Setting the F7MODE_x register to:
• -1 forces the camera to use the factory defined mode
• -2 disables the respective Format_7 mode (no mapping
is applied)
After setup of personal Format_7 mode mappings you
have to reset the camera. The mapping is performed dur-
ing the camera startup only.
Offset Name Field Bit Description
0xF10005B0 LOW_NOISE_BINNING Presence_Inq [0] Indicates presence of this feature
(read only)
--- [1..5] Reserved
ON_OFF [6] Low noise binning mode on/off
--- [7..31] Reserved
Table 158: Advanced register: Low noise binning mode
2
