Camera interfaces
STINGRAY Technical Manual V4.4.4
113
Each component (Y, R, G, B) has 8-bit data. The data type is Unsigned Char.
Each component (Y, U, V) has 8-bit data. The Y component is the same as in
the above table.
Y, R, G, B Signal level (decimal) Data (hexadecimal)
Highest
Lowest
255
254
.
.
1
0
0xFF
0xFE
.
.
0x01
0x00
Figure 49: Data structure of Mono8, RGB8; Source: IIDC V1.31 /
Y(Mono8/Raw8) format: AVT
U, V Signal level (decimal) Data (hexadecimal)
Highest (+)
Lowest
Highest (-)
127
126
.
.
1
0
-1
-127
-128
0xFF
0xFE
.
.
0x81
0x80
0x7F
0x01
0x00
Figure 50: Data structure of YUV8; Source: IIDC V1.31
