Controlling image capture
STINGRAY Technical Manual V4.4.4
204
How is sequence mode implemented?
There is a FIFO (first in first out) memory for each of the IIDC V1.31 registers
listed above. The depth of each FIFO is fixed to 32(dec) complete sets. Func-
tionality is controlled by the following advanced registers.
Note

Sequence mode requires special care if changing image
size, Color_Coding_ID and frame rate related parameters.
This is because these changes not only affect settings in
the camera but also require corresponding settings in the
receiving software in the PC.
Caution

• Incorrect handling may lead to image corruption or
loss of subsequent images.
• Please ask for detailed support if you want to use
this feature.
Register Name Field Bit Description
0xF1000220 SEQUENCE_CTRL Presence_Inq [0] Indicates presence of this feature
(read only)
--- [1..4] Reserved
AutoRewind [5]
ON_OFF [6] Enable/disable this feature
SetupMode [7] Sequence setup mode
--- [8..15] Reserved
MaxLength [16..23] Maximum possible length of a
sequence (read only)
SeqLength [24..31] Length of the sequence (32 dec for
all CCD models)
0xF1000224 SEQUENCE_PARAM --- [0..4] Reserved
ApplyParameters [5] Apply settings to selected image of
sequence; auto reset
--- [6..7] Reserved
SeqStepMode [8..15] Sequence stepping mode
ImageRepeat [16..23] Image repeat counter
ImageNo [24..31] Number of image within a sequence
Table 73: Advanced register: Sequence mode
