Camera dimensions
STINGRAY Technical Manual V4.4.4
78
Stingray W90 S90 (1394b: 1 x GOF, 1 x copper)
This version has the sensor tilted by 90 degrees clockwise, so that it views
upwards.
The sensor is also rotated by 90 degrees clockwise.
Figure 29: Stingray W90 S90 (1394b: 1 x GOF, 1 x copper)
Stingray W90S90 (1394b: 1x GOF, 1x COP)
108 x 44 x 41.6 (L x W x H)
55.5
108
101
47.8
2
6
2
9 4
1
.6
44
9.7
1
9
.3
16 M3 x4 (2x)
1
3
M3 x3 (3x)
M3 x3 (3x)
Q 27
9
.1
-
0
.0
0
.3
+
& -Mount
1
3
.4
-
0
.0
0
.3
+
5
.4
