Format Mode Resolution
Color mode
Maximal S800 frame rates for Format_7 modes
7
0
1624 x 1234
1624 x 1234
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
14 fps
14 fps
14 fps
14 fps
14 fps
14 fps
10 fps
14 fps
1
812 x 1234
812 x 1234
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
14 fps
2x H-binning
14 fps
2x H-binning
14 fps
2x H-binning
14 fps
2x H-binning
14 fps
2x H-binning
14 fps
2x H-binning
14 fps
2x H-binning
14 fps
2x H-binning
2
1624 x 616
1624 x 614
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
26 fps
2x V-binning
26 fps
2x V-binning
26 fps
2x V-binning
26 fps
2x V-binning
26 fps
2x V-binning
26 fps
2x V-binning
21 fps
2x V-binning
26 fps
2x V-binning
3
812 x 616
812 x 614
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
26 fps
2x H+V binning
26 fps
2x H+V binning
26 fps
2x H+V binning
26 fps
2x H+V binning
26 fps
2x H+V binning
26 fps
2x H+V binning
26 fps
2x H+V binning
26 fps
2x H+V binning
4
812 x 1234
812 x 1234
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
14 fps
2 out of 4 H-sub-sampling
Table 89: Video Format_7 default modes Stingray F-201B /
F-201C
