Controlling image capture
STINGRAY Technical Manual V4.4.4
198
One-shot command on the bus to start of
exposure
The following sections describe the time response of the camera using a sin-
gle frame (one-shot) command. As set out in the IIDC specification, this is
a software command that causes the camera to record and transmit a single
frame.
The following values apply only when the camera is idle and ready for use.
Full resolution must also be set.
Microcontroller sync is an internal signal. It is generated by the microcon-
troller to initiate a trigger. This can either be a direct trigger or a release for
ExSync if the camera is externally triggered.
Feature
Value
One-shot microcontroller sync
150 µs (processing time in the
microcontroller)
µC-Sync/ExSync integration start 8 µs
Table 70: Values for one-shot
