STINGRAY Technical Manual V4.4.4
256
Test images for color cameras
The color cameras have 1 test image:
YUV4:2:2 mode
Figure 113: Color test image
Mono8 (raw data)
Figure 114: Bayer-coded test image
The color camera outputs Bayer-coded raw data in Mono8 instead of (as
described in IIDC V1.31) a real Y signal.
Note

The first pixel of the image is always the red pixel from
the sensor. (Mirror must be switched off.)
