Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
234
Stingray F-504B / Stingray F-504C

and board level F-504B BL / F-504C BL
Table 90: Video fixed formats Stingray F-504B / F-504C
Format Mode Resolution Color mode 240
fps
120
fps 60
fps 30
fps 15
fps 7.5
fps 3.75
fps 1.875
fps
0 0 160 x 120 YUV444
1 320 x 240 YUV422 x x x x x
2 640 x 480 YUV411 x x x x
3 640 x 480 YUV422 x x x x
4 640 x 480 RGB8 x x x x
5 640 x 480 Mono8 x x* x x* x x* x x*
6 640 x 480 Mono16 x x x x
1 0 800 x 600 YUV422 x x x
1 800 x 600 RGB8 x x
2 800 x 600 Mono8 x x* x x*
3 1024 x 768 YUV422 x x x x
4 1024 x 768 RGB8 x x x x
5 1024 x 768 Mono8 x x* x x* x x* x x*
6 800 x 600 Mono16 x x x
7 1024 x 768 Mono16 x x x x
2 0 1280 x 960 YUV422 x x x x
1 1280 x 960 RGB8 x x x x
2 1280 x 960 Mono8 x x* x x* x x* x x*
3 1600 x 1200 YUV422 x x x
4 1600 x 1200 RGB8 x x x
5 1600 x 1200 Mono8 x x* x x* x x*
6 1280 x 960 Mono16 x x x x
7 1600 x 1200 Mono16 x x x
* : Color camera outputs Mono8 interpolated image.
Frame rates with shading are only achievable with 1394b (S800).
Note

The following table shows default Format_7 modes with-
out Format_7 mode mapping.
• see Chapter Mapping of possible Format_7 modes to
F7M1...F7M7 on page 160
• see Chapter Format_7 mode mapping on page 327
