Defect pixel correction
Definition
The defect pixel correction mode allows to correct an image with defect pix-
els. Via threshold you can define the defect pixels in an image. Defect pixel
correction is done in the FPGA and defect pixel data can be stored inside the
camera’s EEPROM.
DPC = defect pixel correction
WR = write
RD = read
MEM, Mem = memory
Note
•
Defect pixel correction is always done in Format_7
Mode_0.
•
When using defect pixel correction with binning and
sub-sampling: first switch to binning/sub-sampling
modus and then apply defect pixel correction.
Register
Name
Field
Bit
Description
0xF1000298
DPC_CTRL
Presence_Inq
[0]
Indicates presence of this
feature (read only)
BuildError
[1]
Build defect pixel data that
reports an error, e.g. more
than 256 defect pixels, see
DPDataSize.
---
[2..4]
Reserved
BuildDPData
[5]
Build defect pixel data now
ON_OFF
[6]
Enable/disable this feature
Busy
[7]
Build defect pixel data in
progress
MemSave
[8]
Save defect pixel data to
storage
MemLoad
[9]
Load defect pixel data from
storage
ZeroDPData
[10]
Zero defect pixel data
---
[11..17] Reserved
Mean
[18..24] Calculated mean value (7 bit)
Threshold
[25..31] Threshold for defect pixel
correction
Table 142: Advanced register: Defect pixel correction
