Camera dimensions
STINGRAY Technical Manual V4.4.4
85
Cross section: C-Mount
•
All monochrome Stingrays are equipped with the same model of protec-
tion glass.
•
All color Stingrays are equipped with the same model of IR cut filter.
Adjustment of C-Mount and CS-Mount
The dimensional adjustment cannot be done any more by the customer. All
modifications have to be done by the AVT factory.
If you need any modifications, please contact Customer Care: For phone
numbers and e-mail: See Chapter
Contacting Allied Vision Technologies
Figure 36: Stingray C-Mount dimensions
Adjustment spacer
filter / protection glass
C-Mount
10.1
maximum
protrusion:
1
6
Ш
