Camera dimensions
STINGRAY Technical Manual V4.4.4
77
Stingray W90 S90 (2 x 1394b copper)
This version has the sensor tilted by 90 degrees clockwise, so that it views
upwards.
The sensor is also rotated by 90 degrees clockwise.
Figure 28: Stingray W90 S90 (2 x 1394b copper)
Stingray W90S90 (2x IEEE 1394b)
107.3 x 44 x 41.6 (L x W x H)
