Configuration of the camera
STINGRAY Technical Manual V4.4.4
293
0xF1000240 LUT_CTRL See Table 137: Advanced register: LUT on page
305
0xF1000244 LUT_MEM_CTRL
0xF1000248 LUT_INFO
0xF1000250 SHDG_CTRL See Table 138: Advanced register: Shading on
page 307
0xF1000254 SHDG_MEM_CTRL
0xF1000258 SHDG_INFO
0xF1000260 DEFERRED_TRANS See Table 140: Advanced register: Deferred
image transport on page 310
0xF1000270 FRAMEINFO See Table 141: Advanced register: Frame infor-
mation on page 311
0xF1000274 FRAMECOUNTER
0xF1000298 DPC_CTRL See Table 142: Advanced register: Defect pixel
correction on page 312
0xF100029C DPC_MEM
0xF10002A0 DPC_INFO
0xF1000300 IO_INP_CTRL1 STINGRAY housing and board level cameras

See Table 22: Advanced register: Input control
on page 97
0xF1000304 IO_INP_CTRL2
0xF1000320 IO_OUTP_CTRL1 STINGRAY housing and board level cameras
See Table 28: Advanced register: Output control
on page 103
0xF1000324 IO_OUTP_CTRL2
0xF1000328 IO_OUTP_CTRL3
0xF100032C IO_OUTP_CTRL4
0xF1000340 IO_INTENA_DELAY See Table 143: Advanced register: Delayed Inte-
gration Enable (IntEna) on page 314
0xF1000360 AUTOSHUTTER_CTRL See Table 144: Advanced register: Auto shutter
control on page 315
0xF1000364 AUTOSHUTTER_LO
0xF1000368 AUTOSHUTTER_HI
0xF1000370 AUTOGAIN_CTRL See Table 145: Advanced register: Auto gain
control on page 316
0xF1000390 AUTOFNC_AOI See Table 146: Advanced register: Autofunction
AOI on page 317
0xF1000394 AF_AREA_POSITION
0xF1000398 AF_AREA_SIZE
0xF10003A0 COLOR_CORR Stingray color cameras only
See Table 147: Advanced register: Color correc-
tion on page 318
Register Register name Description
Table 127: Advanced registers summary
