Video formats, modes and bandwidth

STINGRAY Technical Manual V4.4.4

235

Format Mode Resolution

Color mode

Maximal S800 frame rates for Format_7 modes

7

0

2452 x 2056

2452 x 2056

Mono8

Mono12

Mono16

YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12

9 fps

8 fps

6 fps

8 fps

6 fps

9 fps

4 fps

8 fps

1

1224 x 2056 Mono8

Mono12

Mono16

9 fps

2x H-binning

9 fps

2x H-binning

9 fps

2x H-binning

2

2452 x 1028

Mono8

Mono12

Mono16

15 fps

2x V-binning

15 fps

2x V-binning

12 fps

2x V-binning

3

1224 x 1028

Mono8

Mono12

Mono16

15 fps

2x H+V binning

15 fps

2x H+V binning

15 fps

2x H+V binning

4

1224 x 2056

1224 x 2056

Mono8

Mono12

Mono16

YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12

9 fps

2 out of 4 H-sub-sampling

9 fps

2 out of 4 H-sub-sampling

9 fps

2 out of 4 H-sub-sampling

9 fps

2 out of 4 H-sub-sampling

9 fps

2 out of 4 H-sub-sampling

9 fps

2 out of 4 H-sub-sampling

8 fps

2 out of 4 H-sub-sampling

9 fps

2 out of 4 H-sub-sampling

7

5

#

2452 x 1028

2452 x 1028

Mono8

Mono12

Mono16

YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12

9 fps

2 out of 4 V-sub-sampling

9 fps

2 out of 4 V-sub-sampling

9 fps

2 out of 4 V-sub-sampling

9 fps

2 out of 4 V-sub-sampling

9 fps

2 out of 4 V-sub-sampling

9 fps

2 out of 4 V-sub-sampling

8 fps

2 out of 4 V-sub-sampling

9 fps

2 out of 4 V-sub-sampling

6

#

1224 x 1028

1224 x 1028

Mono8

Mono12

Mono16

YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

9 fps

2 out of 4 H+V sub-sampling

Table 91: Video Format_7 default modes Stingray F-504B /

F-504C
