Camera interfaces
STINGRAY Technical Manual V4.4.4
105
Figure 47: Output impulse diagram
Note

The signals can be inverted.
Caution

Firing a new trigger while IntEna is still active can result
in missing image.
External trigger input
IntEna delayed
IntegrationEnable (IntEna)
Busy
FrameValid (FVal)
Delay set by

Trigger_Delay register
Delay set by

IntEna_Delay register
WaitingForTrigger (only edge mode)
