Configuration of the camera
STINGRAY Technical Manual V4.4.4
267
Inquiry register for video mode
Offset Name Field Bit Description Color mode
180h V_MODE_INQ
(Format_0)
Mode_0 [0] 160 x 120 YUV 4:4:4
Mode_1 [1] 320 x 240 YUV 4:2:2
Mode_2 [2] 640 x 480 YUV 4:1:1
Mode_3 [3] 640 x 480 YUV 4:2:2
Mode_4 [4] 640 x 480 RGB
Mode_5 [5] 640 x 480 MONO8
Mode_6 [6] 640 x 480 MONO16
Mode_X [7] Reserved
--- [8..31] Reserved (zero)
184h V_MODE_INQ
(Format_1)
Mode_0 [0] 800 x 600 YUV 4:2:2
Mode_1 [1] 800 x 600 RGB
Mode_2 [2] 800 x 600 MONO8
Mode_3 [3] 1024 x 768 YUV 4:2:2
Mode_4 [4] 1024 x 768 RGB
Mode_5 [5] 1024 x 768 MONO8
Mode_6 [6] 800 x 600 MONO16
Mode_7 [7] 1024 x 768 MONO16
--- [8..31] Reserved (zero)
188h V_MODE_INQ
(Format_2)
Mode_0 [0] 1280 x 960 YUV 4:2:2
Mode_1 [1] 1280 x 960 RGB
Mode_2 [2] 1280 x 960 MONO8
Mode_3 [3] 1600 x 1200 YUV 4:2:2
Mode_4 [4] 1600 x 1200 RGB
Mode_5 [5] 1600 x 1200 MONO8
Mode_6 [6] 1280 x 960 MONO16
Mode_7 [7] 1600 x 1200 MONO16
--- [8..31] Reserved (zero)
18Ch
…
197h
Reserved for other V_MODE_INQ_x for Format_x. Always 0
198h V_MODE_INQ_6 (Format_6) Always 0
Table 116: Video mode inquiry register
