Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
218
Format Mode Resolution Color mode Maximal S800 frame rates for Format_7 modes
7
0 780 x 580


780 x 580
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
61 fps

61 fps

61 fps
61 fps

61 fps

61 fps

48 fps

61 fps
1 388 x 580 Mono8

Mono12

Mono16
61 fps 2x H-binning

61 fps 2x H-binning

61 fps 2x H-binning
2 780 x 290 Mono8

Mono12

Mono16
111 fps 2x V-binning

111 fps 2x V-binning

111 fps 2x V-binning
3 388 x 290 Mono8

Mono12

Mono16
111 fps 2x H+V binning

111 fps 2x H+V binning

111 fps 2x H+V binning
4 388 x 580


388 x 580
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
61 fps 2 out of 4 H-sub-sampling

61 fps 2 out of 4 H-sub-sampling

61 fps 2 out of 4 H-sub-sampling
61 fps 2 out of 4 H-sub-sampling

61 fps 2 out of 4 H-sub-sampling

61 fps 2 out of 4 H-sub-sampling

61 fps 2 out of 4 H-sub-sampling

61 fps 2 out of 4 H-sub-sampling
5 780 x 290


780 x 290
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
79 fps 2 out of 4 V-sub-sampling

79 fps 2 out of 4 V-sub-sampling

79 fps 2 out of 4 V-sub-sampling
79 fps 2 out of 4 V-sub-sampling

79 fps 2 out of 4 V-sub-sampling

79 fps 2 out of 4 V-sub-sampling

79 fps 2 out of 4 V-sub-sampling

79 fps 2 out of 4 V-sub-sampling
6 388 x 290


388 x 290
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
79 fps 2 out of 4 H+V sub-sampling

79 fps 2 out of 4 H+V sub-sampling

79 fps 2 out of 4 H+V sub-sampling
79 fps 2 out of 4 H+V sub-sampling

79 fps 2 out of 4 H+V sub-sampling

79 fps 2 out of 4 H+V sub-sampling

79 fps 2 out of 4 H+V sub-sampling

79 fps 2 out of 4 H+V sub-sampling
Table 79: Video Format_7 default modes Stingray F-046B / Stingray F-046C
