Configuration of the camera
STINGRAY Technical Manual V4.4.4
290
024h
.
.
033h
COLOR_CODING_INQ
Vendor Unique Color_Coding
0-127 (ID=128-255)
ID=132 ECCID_MONO12
ID=136 ECCID_RAW12
ID=133
Reserved
ID=134
Reserved
ID=135
Reserved
034h
PIXEL_NUMER_INQ
According to IIDC V1.31
038h
TOTAL_BYTES_HI_INQ
According to IIDC V1.31
03Ch
TOTAL_BYTES_LO_INQ
According to IIDC V1.31
040h
PACKET_PARA_INQ
See note
044h
BYTE_PER_PACKET
According to IIDC V1.31
Note
•
For all modes in Format_7, ErrorFlag_1 and
ErrorFlag_2 are refreshed on each access to the
Format_7 register.
•
Contrary to IIDC V1.31, registers relevant to Format_7
are refreshed on each access. The Setting_1 bit is
automatically cleared after each access.
•
When ErrorFlag_1 or ErrorFlag_2 are set and Format_7
is configured, no image capture is started.
•
Contrary to IIDC V1.31, COLOR_CODING_ID is set to a
default value after an INITIALIZE or reset.
•
Contrary to IIDC V1.31, the UnitBytePerPacket field is
already filled in with a fixed value in the
PACKET_PARA_INQ register.
Offset
Name
Description
Table 125: Format_7 control and status register
