Filter and lenses
STINGRAY Technical Manual V4.4.4
45
Focal length

for type 1/1.8 sensors

Stingray F-201
Distance = 500 mm Distance = 1000 mm
4.8 mm 740 mm x 549 mm 1488 mm x 1103 mm
8 mm 441 mm x 327 mm 890 mm x 660 mm
12 mm 292 mm x 216 mm 591 mm x 438 mm
16 mm 217 mm x 161 mm 441 mm x 327 mm
25 mm 136 mm x 101 mm 280 mm x 207 mm
35 mm 95 mm x 71 mm 198 mm x 147 mm
50 mm 65 mm x 48 mm 136 mm x 101 mm
Table 9: Focal length vs. field of view (Stingray F-201)
Focal length

for type 2/3 sensors

Stingray F-145/504
Distance = 500 mm Distance = 1000 mm
4.8 mm 908 mm x 681 mm 1825 mm x 1368 mm
8 mm 541 mm x 406 mm 1091 mm x 818 mm
12 mm 358 mm x 268 mm 725 mm x 543 mm
16 mm 266 mm x 200 mm 541 mm x 406 mm
25 mm 167 mm x 125 mm 343 mm x 257 mm
35 mm 117 mm x 88 mm 243 mm x 182 mm
50 mm 79 mm x 59 mm 167 mm x 125 mm
Table 10: Focal length vs. field of view (Stingray F-145)
Note

Lenses with focal lengths < 8 mm may show shading in
the edges of the image and due to micro lenses on the
sensor's pixel.
Ask your dealer if you require non C-Mount lenses.
