Introduction
STINGRAY Technical Manual V4.4.4
13
continued from last page
V2.1.0
[continued]
23.05.08
[continued]
Added 4 x and 8 x binning in

Chapter Binning (only Stingray b/w and F-201C/504C) on page
146ff.
Added 2 out of 8 sub-sampling in Chapter Sub-sampling (Sting-
ray b/w and color) on page 152ff.
Changed Figure 87: Mapping of possible Format_7 modes to
F7M1...F7M7 on page 160
Added fiber models in Table 54: FIFO memory size on page 169
Added Chapter Temperature register on page 291
Added Shading control registers (0xF1000250, 0xF1000254,
0xF1000258) in
Table 127: Advanced registers summary on page
292ff.
Added Mirror image register (0xF1000410) in Table 127:
Advanced registers summary on page 292ff.
Added board level variants in Table 129: Camera type ID list on
page 297
Added Shading and Mirror image in Table 130: Advanced regis-
ter: Advanced feature inquiry on page 298
Added Chapter Shading correction on page 307ff.
Added Chapter Mirror image on page 319
Added Appendix Chapter Sensor position accuracy of AVT
FireWire cameras on page 341
Added 0x09 PWM in Table 29: Output routing on page 104
Added Chapter Board level camera: IEEE 1394b port pin assign-
ment on page 91
Added Chapter Board level camera: I/O pin assignment on page
93
Added PWM feature in Chapter IO_OUTP_CTRL 1-4 on page
103ff.
Added Pulse-width modulation (Stingray housing and Stingray
board level models) on page 106
Added PWM feature in Table 29: Output routing on page 104.
to be continued on next page
Version Date Remarks
Table 1: Document history
