• Shading correction in Format_7 mode 0 (Mono8) is only
available up to S400: see note in Chapter
Building shading
image in Format_7 modes on page 130
Some smaller corrections:
• At register 0xF1000200 changed width and height: see
Table 132: Advanced register: Maximum resolution inquiry
on page 301
• YUV8: deleted description of data type straight binary:
Figure 50: Data structure of YUV8; Source: IIDC V1.31 on
page 113
• Y (Mono8/Raw8) are AVT own formats: see Table 35: Y
(Mono8) format: Source: IIDC V1.31 / Y (Raw8) format:
AVT
on page 86
V4.4.3 15.03.2012 Some smaller corrections:
• User sets changed: LUT and on/off bit can be stored in
user settings: see Chapter
Stored settings on page 338
• Stingray F-504C provides 2 out of 8 horizontal sub-
sampling: see
Figure 80: Horizontal sub-sampling 2 out of
8 (color) on page 153
• Corrected: max. gain for Stingray F-504B/C is 670 and not
680, see Chapter
Manual gain on page 127
• Corrected: Stingray F-504B/C: range in dB is 0 .. 24.053
(not 24.4), see see Chapter
Manual gain on page 127 and
Chapter STINGRAY F-504B/C (fiber) on page 60
• Changed: number of steps from +/-40 to +/-128 in steps
of 1/12.8° in Chapter
Hue and saturation on page 176
Changed fixed format modes and Format 7 modes:
• Table 80: Video fixed formats Stingray F-080B / F-080C on
page 219
• Table 96: Frame rates (fps) of Stingray F-033 as function of
AOI height (pixel) [width=656]
on page 245
• Table 97: Frame rates (fps) of Stingray F-046 as function of
AOI height (pixel) [width=780]
on page 246
• Table 98: Frame rates (fps) of Stingray F-080 as function of
AOI height (pixel) [width=1032]
on page 247
• Table 99: Frame rates (fps) Stingray F-125 as function of
AOI height (pixel) [width=1292]
on page 248
• Table 100: Frame rates (fps) Stingray F-145 as function of
AOI height (pixel) [width=1388]
on page 249
• Table 101: Frame rates (fps) of Stingray F-146 as function
of AOI height (pixel) [width=1388]
on page 250
• Table 102: Frame rates of Stingray F-201 as function of AOI
height [width=1624]
on page 251
• Table 103: Frame rates of Stingray F-504 as function of AOI
height [width=2452]
on page 252
to be continued on next page
