Camera interfaces
STINGRAY Technical Manual V4.4.4
91
Board level camera: IEEE 1394b port pin
assignment
Board level STINGRAY cameras have two 1394b ports to allow daisy chaining
of cameras.
They have the same pin assignment as the STINGRAY housing cameras.
Figure 41: Board level camera: two IEEE 1394b FireWire connectors
sensor board
1 = GND (for RS232, Ext PWR)
2 = Ext PWR input
(PWR output on demand)
3 = Output 4
4 = Input 1
5 = Output 3
6 = Output 1
FFC45 cable length:
-----------------------------
FFC45 L = 56 mm K7500307
FFC45 L = 110 mm K7500318
FFC45 cable
2
2x HOLE
2.9mm PTH
2.3 mm
PTH
2.3 mm
PTH
2
41
4
0
2
IO-AD-Board
processor board
interface board
2x IEEE 1394b
25 2
2
8
.7
1
5
4
.5 6
.6 1
1
.2 1
5
.4
27
1 13
spacer M2x10 (4x)
7 = GND (for Inputs)
8 = RxD 9 = TxD
10 = Power Input
(for Output ports)
11 = Input 2
12 = Output 2
13 = Cable Shield
12
2
8
.9
3
.1
13-pole I/O connector:
[Molex 1.25mm Pitch PicoBlade Wire-to-Board Header (53047-1310)]
----------------------------------------------------------------------------------
13-pole connector 9.1
Q
2
7
2
9
front flange with C-Mount adapter
3
6
2
6.5 12
PCB Spacer M2x5
GNDChassis
1n
1M
GND
J3
1
GNDChassis
1n
1M
GND
PCB Spacer M2x5
J2
1
J2
J3
