Introduction
STINGRAY Technical Manual V4.4.4
21
continued from last page
V4.3.0
15.09.09
Minor corrections:
•
Notice about connection between temperature at sensor
and temperature at camera housing on page 291.
•
Corrected registers for IO_OUTP_PWM2/3/4 in
•
Revised Chapter
•
New drawings to show maximum protrusion:
on page 84 and
•
New values for maximum protrusion: tables in Chapter
•
Corrected addresses of debounce registers:
– Advanced register summary
– Advanced register summary
– Advanced register summary
– Advanced register summary
–
Table 64: Advanced register: Debounce time for input
ports
•
Stingray cameras with serial numbers S/N greater
09/17-285831532 have a heat sink and thus the mass of
the camera increases from 92 g up to 108 g: see Chapter
on page 46ff.
New front flange:
•
Title page: new Stingray photo
•
New CAD drawings:
– All CAD drawings in Chapter
– Cross section drawings in
on page 85. Note: Adjustments by means
of the adjustment spacer(s) have to to be done in the
AVT factory. Contact Customer Care.
–
Figure 41: Board level camera: two IEEE 1394b FireWire
connectors
–
Figure 43: Board level camera: I/O pin assignment
2x/4x/8x binning:
Stingray F-504C has now also the usual 2x/4x/8x binning (no
color binning): see Chapter
Binning (only Stingray b/w and F-
Table 18: Specification STING-
to be continued on next page
Version
Date
Remarks
Table 1: Document history
