Hierarchy Display
3Ć40
MTG100 & MTG300 MPEG Generator User Manual
Table 3-39 describes the text information and Table 3-40 describes the Bezel
menu commands for the Program Allocation Table (PAT) icon.
Table 3Ć39: PAT icon text descriptions
Parameter Description
PID Shows the PID value of the PAT.
TS ID Shows the transport_stream_id value of the PAT.
Table ID Shows the table_id value of the PAT.
Interval Shows the period of the PAT.
Num of Program Shows the number of programs contained in the transport stream.
Table 3Ć40: PAT icon Bezel menu commands (MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
PAT.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Interval... Changes the period of the PAT.
When you select this menu item, the PAT Interval dialog box appears.
Refer to PAT Interval Dialog Box on page 3Ć41 for more information.
Note: If the pointer_field value of the transport stream is not 0, this
command is not available.
Reset Replace Cancels the data replacement activated by the Replace Section...
command and restores the originaldata.
Program Allocation Table
(PAT) Icon
