Pull-down Menus
MTG100 & MTG300 MPEG Generator User Manual
3Ć5
When you select the Open TS File... command from the FILE pull-down menu,
the Select TS File dialog box appears as shown in Figure 3-1. Use the rotary
knob or the arrow buttons to highlight the desired file. Press the OK bezel button
or the left control button to load the highlighted file.
Table 3-2 describes the Select TS File dialog box parameters and Table 3-3
describes the Bezel menu commands associated with the dialog box.
Figure 3Ć1: Select TS File dialog box
Table 3Ć2: Select TS File dialog boxparameters
Parameter Description
Drive Shows the disk drive containing the transport stream files.
Directory Shows the directory path of the files listed under Filename. The default
directory is /main/usr/ts.
Filename Lists the files in the current directory path.
Table 3Ć3: Bezel menu commands for the Select TS File dialog box
Command Description
Up Level Moves from the current directory to the directory one level higher.
Down Level Moves from the current directory to the selected lowerĆlevel directory.
Update Updates the list of files under Filename for the selected directory.
Cancel Cancels the Select TS File operation and closes the dialog box.
OK Executes the Select TS File operation and closes the dialog box.
Select TS File Dialog Box
