Hierarchy Display
3Ć74
MTG100 & MTG300 MPEG Generator User Manual
Table 3-94 describes the text information and Table 3-95 describes the Bezel
menu commands for the System Time Table (STT) icon.
Table 3Ć94: STT icon text descriptions
Parameter
Description
PID
Shows the PID value of the STT.
Table ID
Shows the table_id value of the STT.
System Time
Shows the system type of the STT.
Initial Time
Shows the initial data and time (year / month / day hour : minute :
second) of the STT.
Interval
Shows the period of the STT.
GPS UTC Offset
Shows the GPS_UTC_offset value.
DS Mode
Shows the Daylight Savings Time mode setting.
DS In
Shows the date and time when Daylight Savings time starts.
DS Out
Shows the date and time when Daylight Savings time ends.
Table 3Ć95: STT icon Bezel menu commands(MTG300 only)
Command
Description
Stress TS Head...
Changes the status of the packet header in the packet containing the
STT.
When you select this menu item, the TS Head Stress dialogbox
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
STT...
Changes the period and initial time of the STT.
When you select this command, the STT Item dialogbox appears. Refer
to STT Item Dialog Box on page 3Ć15 for more information.
Stress SI...
Changes the status of the section header in the STT.
When you select this menu item, the Stress SI dialogbox appears.
Refer to Stress SI Dialog Box on page 3Ć61 for more information.
Reset Replace
Cancels the data replacement activated by the Replace Section...
command and restores the original data.
System Time Table (STT)
Icon
