Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć29
Table 3Ć26: Icons specific to DVB format
Icon Element type
Service Description Table (SDT)
One or more transport packets witha PID value of 0x0011 and a table_id value
of 0x42.
Bouquet Association Table (BAT)
One or more transport packets witha PID value of 0x0011 and a table_id value
of 0x4A.
Event Information Table (EIT)
One or more transport packets witha PID value of 0x0012 and a table_id value
of 0x4E-0x6F.
Running Status Table (RST)
One or more transport packets witha PID value of 0x0013 and a table_id value
of 0x4E-0x71.
Stuffing Table (ST)
One or more transport packets witha PID value of 0x0010-0x0013 and a
table_id value of 0x72.
Discontinuity Information Table (DIT)
One or more transport packets witha PID value of 0x1E and a table_id value of
0x7E.
Selection Information Table (SIT)
One or more transport packets witha PID value of 0x1F and a table_id value of
0x7F.
Time and Data Table (TDT)
One or more transport packets witha PID value of 0x0014 and a table_id value
of 0x72.
Time Offset Table (TOT)
One or more transport packets witha PID value of 0x0014 and a table_id value
of 0x73.
