Appendix B: Using MTG Comm
+
for File Transfers
BĆ24
MTG100 & MTG300 MPEG Generator User Manual
Yes
No
1
No
Yes
Start
Non TS file
MĆTMCC file
Are W1 and W2
detected?
Is Sync_byte detected
and its packet size
decided?
Check that sync_byte (0x47) exists within 5 sequential
packets in a range from the top of the file to the 9,792th
(204X48) byte, and that the size of these packets is 188,
204,or 208 bytes.
* In this case, data located before sync_byte are
regarded as invalid data (invalid data #1).
Divide the invalid data #1 by the packet size, and let the
reminder of division be the invalid data #2, and let the
rest be the first packet.
Check that Sync_Word (W1 and W2) exists on the
specified location in a range from the first packet to the
88.128th byte (204X48X9, SF size +a).
Figure BĆ10: Automatic recognition of standard (1)
