Hierarchy Display
3Ć62
MTG100 & MTG300 MPEG Generator User Manual
Table 3-74 describes the text information and Table 3-75 describes the Bezel
menu commands for the Entitlement Management Message (EMM) icon. The
items labeled “Section data only” do not appear when the EMM is a PES
(Packetized Elementary Stream) packet.
Table 3Ć74: EMM icon text descriptions
Parameter Description
PID Shows the PID value of the EMM.
Table ID Shows the table_idvalue of the EMM.
Interval Shows the periodof the EMM.
Table 3Ć75: EMM icon Bezel menu commands (MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
EMM.
When you select this menu item, the TS HeadStress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Stress SI...
(Section data only)
Changes the status of the section header in the EMM.
When you select this menu item, the Stress SI dialog box appears.
Refer to Stress SI Dialog Box on page 3Ć61 for more information.
Reset Replace
(Section data only)
Cancels the data replacement activated by the Replace Section...
commandandrestores the original data.
Replace Section...
(Section data only)
Replaces the current EMM with the specifiedsection data (section file).
When you select this command, the Select Replace File dialog box
opens listing the files in the /main/usr/insert directory on the hard drive.
The Select Replace File dialog box functions similar to the Select TS
File dialog box shown in Figure 3Ć1 on page 3Ć5.
After you select a replacement file, the Replace SetupĂdialog box
appears. Refer to Replace Setup Dialog Box on page 3Ć42 for more
information. Refer to Replacing and Inserting Section Data (MTG300
Only) on page 3Ć81 for detailed information about section replacement.
Del Packet Toggles the Delete Packet function between Inactive andActive.
Inactive: Cancels the delete packet operation.
Active: Deletes the selecteditem from the transport stream. If other
items with the same PID value as the selecteditem exist in the transport
stream andthey are containedin one packet, they are also deletedfrom
the transport stream (except for the PCR). When the item is deleted, the
item information is shaded in the hierarchy display.
Entitlement Management
Message (EMM) Icon
