Hierarchy Display
3Ć68
MTG100 & MTG300 MPEG Generator User Manual
Table 3-88 describes the text information and Table 3-89 describes the Bezel
menu commands for the Time and Data Table (TDT) and Time Offset Table
(TOT) icons.
Table 3Ć88: TDT and TOT icon text descriptions
Parameter Description
PID Shows the PID value of the TDT or TOT.
Table ID Shows the table_id value of the TDT or TOT.
Interval Shows the period of the TDT or TOT.
Table 3Ć89: TDT and TOT icon Bezel menu commands (MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
TDT or TOT.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
TDT... or TOT... Changes the period and initial time of the TDT or TOT.
When you select this command, the TDT Item or TOT Item dialog box
appears. Refer to TOT Item Dialog Box on page 3Ć14 for more
information.
Stress SI... Changes the status of the section header in the TDT or TOT.
When you select this menu item, the Stress SI dialog box appears.
Refer to Stress SI Dialog Box on page 3Ć61 for more information.
Reset Replace Cancels the data replacement activated by the Replace Section...
command and restores the original data.
TDT and TOT Icon
