Tutorials

This section provides the following tutorials to familiarize you with the basic
functions of the MPEG generator:

H Outputting a transport stream

H Changing the PCR interval (MTG300 only)

H Inserting an EIT (MTG300 only)

NOTE. These tutorials do not cover all the features and functions of the MPEG
generator. The tutorials are intended to introduce you to the operations required
to execute the instrument’s basic functions.

Refer to the Reference section for detailed descriptions of the menus and
functions used in these procedures.

Before you perform these tutorials, make sure that the MPEG generator is
properly installed. Refer to Installation on page 1-6.

Required Equipment

Table 2-3 lists the equipment required to perform the tutorials. Accuracy of
alternate equipment should equal or exceed that of the example instruments and
accessories. Using inadequate equipment may result in inaccurate measurements.

Table 2Ć3: Tutorial recommended test equipment and accessories

Item

No.

Requirements

Example

БББББББББ

БББББББ

БББББББББ

MPEG test system

ББ

БББББББББББББ

БББББББББББ

БББББББББББББ

БББББББББББ

БББББББББББББ

Tektronix MTS200 Series Real Time Analyzer

orequivalent

БББББББББ

75 W BNC coax cable

ББ

БББББББББББББ

Tektronix p/n 012Ć0074Ć00
