Hierarchy Display
3Ć30
MTG100 & MTG300 MPEG Generator User Manual
Table 3Ć27: Icons specific to ARIB format
Icon Element type
Service Description Table (SDT)
Oneor moretransport packets with a PID valueof 0x0011 and a table_id value
of 0x42.
Bouquet Association Table (BAT)
Oneor moretransport packets with a PID valueof 0x0011 and a table_id value
of 0x4A.
Event Information Table (EIT)
Oneor moretransport packets with a PID valueof 0x0012 and a table_id value
of 0x4E-0x6F.
Running Status Table(RST)
Oneor moretransport packets with a PID valueof 0x0013 and a table_id value
of 0x4E-0x71.
Stuffing Table(ST)
Oneor moretransport packets with a PID valueof 0x0010-0x0013 and a
table_id value of 0x72.
Discontinuity Information Table(DIT)
Oneor moretransport packets with a PID valueof 0x1E and a table_id valueof
0x7E.
Selection Information Table (SIT)
Oneor moretransport packets with a PID valueof 0x1F and a table_id valueof
0x7F.
Local event Information Table (LIT)
Oneor moretransport packets with a PID valueof 0x0020 and a table_id value
of 0xD0.
One or more transport packets with a PID value specified by the elementary_PID
in thePMT and a table_id valueof 0xD0 when a stream typevalueis 0x05.
Event Relation Table (ERT)
Oneor moretransport packets with a PID valueof 0x0021 and a table_id value
of 0xD1.
One or more transport packets with a PID value specified by the elementary_PID
in thePMT and a table_id valueof 0xD1 when a stream typevalueis 0x05.
Index Transmission Table (ITT)
One or more transport packets with a PID value specified by the elementary_PID
in thePMT and a table_id valueof 0xD2.
