Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć47
Table 3Ć49: CAT icon Bezel menu commands (MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
CAT.
When you select this menu item, the TS Head Stress dialogbox
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Stress SI... Changes the status of the section header in the CAT.
When you select this menu item, the Stress SI dialogbox appears.
Refer to Stress SI Dialog Box on page 3Ć61 for more information.
Reset Replace Cancels the data replacement activated by the Replace Section...
command and restores the original data.
Replace Section... Replaces the current CAT with the specified section data (section file).
When you select this command, the Select Replace File dialogbox
opens listingthe files in the /main/usr/insert directory on the hard drive.
The Select Replace File dialogbox functions similar to the Select TS
File dialog box shown in Figure 3Ć1 on page 3Ć5.
After you select a replacement file, the Replace SetupĂdialogbox
appears. Refer to Replace Setup Dialog Box on page 3Ć42 for more
information. Refer to Replacing and Inserting Section Data (MTG300
Only) on page 3Ć81 for detailed information about section replacement.
Del Packet Toggles the Delete Packet function between Inactive and Active.
Inactive: Cancels the delete packet operation.
Active: Deletes the selected item from the transport stream. If other
items with the same PID value as the selected item exist in the transport
stream and they are contained in one packet, they are also deleted from
the transport stream (except for the PCR). When the item is deleted, the
item information is shaded in the hierarchy display.
