Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć31
Table 3Ć27: Icons specific to ARIB format (Cont.)
Icon Element type
Partial Content Announcement Table (PCAT)
One or more transport packets with a PID value of 0x22 and a table_id value of
0xC2.
Software Download Trigger Table (SDTT)
One or more transport packets with a PID value of 0x23 and a table_id value of
0xC3.
Download Control Table (DCT)
One or more transport packets with a PID value of 0x17 and a table_id value of
0xC0.
БББББББББББББББББББББ
Б БББББББББББББББББББ Б
Б БББББББББББББББББББ Б
Б БББББББББББББББББББ Б
Б БББББББББББББББББББ Б
БББББББББББББББББББББ
DownLoad Table (DLT)
One or more transport packets with a PID value specified by the DL_PID in the
DCT and a stream_type value of 0xC1.
A lock symbol appears in the icon when the transport_scrambling_control value
is set to 01.
Time and Data Table (TDT)
One or more transport packets with a PID value of 0x0014 and a table_id value
of 0x72.
Time Offset Table (TOT)
One or more transport packets with a PID value of 0x0014 and a table_id value
of 0x73.
