Appendix B: Using MTG Comm + for File Transfers
BĆ18
MTG100 & MTG300 MPEG Generator User Manual
The Remote menu contains commands that load the transport stream file or
preset file and control the data output of the MPEG generator. Table B-6
describes each of the Remote menu commands.
Table BĆ7: MTG Comm + Remote menu commands
Command Function
Load Loads the selected stream file or preset file.
Run Starts the stream output on the MPEG generator.
Stop Stops the stream output on the MPEG generator.
The Utility menu contains commands for setting the network parameters.
Table BĆ8: MTG Comm + Utility menu commands
Command Function
Network Opens the Ethernet dialog box where you can set the host name
(IP address) and port number of the target MPEG generator. Refer
to Ethernet Parameters for MTG Comm + on page BĆ6 for more
information.
Check Error Opens the MTG Error dialog box which lists the error(s) detected in
the MPEG generator.
Options Opens the Set Options dialog box where you can specify whether or
not the ISDB_S files (SĆTMCC file and MĆTMCC file) are checked in
the standard detemination procedures and which text editor
application you will use to describe a private section definition file in
the User Check dialog box. Refer to Set Options Dialog Box on page
BĆ19 for detailed information about the dialog box parameters.
Remote Menu
Utility Menu
