Appendix B: Using MTG Comm
+
for File Transfers
MTG100 & MTG300 MPEG Generator User Manual
BĆ25
No
Yes
1
SĆTMCC file
MPEG2, ATSC, DVB or ARIB file
Do all of the
conditions satisfied?
Perform the following checks in a range from the first
packet to the (26X8)th packet:
1. Is the packet size 204?
2. Search for a packet in which Super Frame Flag of
TMCC basic information is set.
3. Is Frame Flag set in such packet?
4. Search for the next Frame Flag On (let the number of
packets between the first and the next such packet
be the number of slots).
5. Is the number of slots less than 26?
6. Search for the next Frame Flag On.
7. Does the number of slots satisfy the condition
number of slots X8=Super Frame"?
8. Does TMCC basic information located in 4 sequential
packets starting from Super Frame Flag On coincide
(excluding Flag)?
Figure BĆ11: Automatic recognition of standard (2)
