Appendix B: Using MTG Comm + for File Transfers
BĆ20
MTG100 & MTG300 MPEG Generator User Manual
MTG Comm + Tutorials
After you have connected the MPEG generator to the PC using an Ethernet cable
and set the required network parameters, you can use MTG Comm
+ to transfer
files between the PC and the MPEG generator.
NOTE. The convention used by the MTG Comm + application is to call file
transfers from the PC to the MPEG generator a “download,” and to call file
transfers from the MPEG generator to the PC an “upload.”
This subsection provides the procedures to download a stream file, an insertion
file, or a preset file from the PC to the MPEG generator.
Stream File. Perform the following steps to download a stream file from the PC
to the MPEG generator:
1. Select PC to MTG... from the File pull-down menu to open the PC to MTG
Download dialog box.
2. In the PC to MTG Download dialog box, highlight the stream file on the PC
that you want to download, and then click the Download button to open the
User Check dialog box shown in Figure B-5 on page B-13.
CAUTION. Refer to Transport Stream File Requirements on page B-7 for
important information about the requirements for transport stream files you may
want to transfer. Be sure to read the Caution note on page B-8 before you
operate the User Check dialog box.
3. Select the desired parameters in the User Check dialog box, and then click
the OK button to download the file. Refer to User Check Dialog Box on
page B-13 for more information.
NOTE. You can download more than one stream file from the PC to the MPEG
generator using drag-and-drop operation.
Downloading a File to the
MPEG Generator
