Appendix A: Specifications
AĆ8
MTG100 & MTG300 MPEG Generator User Manual
Table AĆ4: Environmental characteristics
Characteristics Description
Temperature
Operating +5_ C to +40_ C
NonĆoperating -20_ C to +60_ C
Relative humidity
Operating 20% to 80% (No condensation)
Maximum wetĆbulb temperature 29.4_ C
NonĆoperating 5% to 90% (No condensation)
Maximum wetĆbulb temperature 40.0_ C
Altitude
Operating To 4.5 km (15,000 feet).
Maximum operating temperature decreases 1_ C each 300 m above 1.5 km.
NonĆoperating To 15 km (50,000 feet).
Dynamics
Vibration
Operating 0.27 g
rms
, 5 to 500 Hz, 10 min, three axes
NonĆoperating 2.28 g
rms
, 5 to 500 Hz, 10 min, three axes
Shock
NonĆoperating 294 m/s 2 (30 G), halfĆsine, 11 ms duration.
Installation requirements
Power consumption 200 W maximum. Maximum line current is 2 A
rms
at 50 Hz.
Dissipation (fully loaded) 90 Vline, with 5% clipping
Surge current
x 30 A peak for less than 5 line cycles at 25_C after product has been off for at least 30 s.
Cooling clearance
Top clearance 5.0 cm
Side clearance 15 cm
Rear clearance 7.5 cm
