Hierarchy Display
3Ć78
MTG100 & MTG300 MPEG Generator User Manual
Table 3-103 describes the text information and Table 3-104 describes the Bezel
menu commands for the INS_TDT (TDT inserted by the MPEG generator) and
INS_TOT (TOT inserted by the MPEG generator) icons.
Table 3Ć103: INS_TDT and INS_TOT icons text descriptions
Parameter Description
PID Shows the PID value of the TDT or TOT.
Table ID Shows the table_id value for the TDT or TOT.
Packets Shows the totalnumber of packets in the TDT or TOT.
InitialTime Shows the initialdate and time of the TDT or TOT.
Interval Shows the time intervalbetween TDT or TOT.
Table 3Ć104: INS_TDT and INS_TOT icons Bezel menu commands
(MTG300 only)
Command Description
TDT... or TOT... Changes the period and initialtime of the TDT or TOT. This command is
only available when the selected transport stream file is in ARIB or DVB
formats and a TDT or TOT does not already exist in the stream.
When you select this command, the TDT Item or TOT Item dialog box
appears. Refer to TOT Item Dialog Box on page 3Ć14 for more
information.
Reject Deletes the INS_TDT or INS_TOT icon and cancels all of the settings.
INS_TDT and INS_TOT
Icons
