Appendix A: Specifications
MTG100 & MTG300 MPEG Generator User Manual
AĆ3
Table AĆ1: Functional characteristics (Cont.)
Characteristics Description
Delete packet MTG300 only
Target packet Deletes the selected item from the transport stream. If other items with the same PID value as
the selected item exist in the transport stream and they are contained in one packet, they are
also deleted from the transport stream (except for the PCR).
PCR interval setting MTG300 only
PCR interval 20 ms to 10.000 s (1 ms resolution)
PCR interval jitter adder MTG300 only
Target PCR Selected one PCR
Reference period 20 ms to 10.000 s (1 ms resolution)
Jitter Pattern sine, rectangle, triangle, pulse, ramp, and random
Jitter Duty 1 to (period-1) packet(s) (available for pulse)
Jitter Period 5 to 3000 packets
Jitter Amplitude 100 to 10 ms (10 ms resolution)
PCR value jitter adder MTG300 only
Target PCR Selected one PCR.
Jitter Pattern sine, rectangle, triangle, pulse, ramp, random, and offset
Jitter Duty 1 to (period-1) packet(s) (only available for pulse jitter pattern)
Jitter Period 5 to 3000 packets (except for the offset mode)
Jitter Amplitude 1 to 60 s (resolution of 37 ns, 27 MHz clock)
TS header change MTG300 only
Number of packets 1 to 65535 packets (on every manual operation)
0 value means that the selected operation is executed infinitely.
Target of change word
operation
Sync_Byte (8)
Transport_error_indicator (1)
payload_unit_start_indicator (1)
transport_priority (1)
PID (13)
transport_scrambling_control (2)
adaptation_field_control (2)
Target packet is all the items or one selected item.
Target of Lack/Duplicate
operation
continuity_counter (4)
Target packet is one selected item.
