Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć65
Table 3-80 describes the text information and Table 3-81 describes the Bezel
menu commands for the Adaptation Field Error (ADFERR) icon.
Table 3Ć80: ADFERR icon text descriptions
Parameter Description
PID Shows the PID value of the ADFERR.
Packet Rate Shows the average output rate of the packet.
Table 3Ć81: ADFERR icon Bezel menu commands (MTG300 only)
Command Description
Del Packet Toggles the Delete Packet function between Inactive and Active.
Inactive: Cancels the delete packet operation.
Active: Deletes the selected item from the transport stream. If other
items with the same PID value as the selected item exist in the transport
stream and they are contained in one packet, they are also deleted from
the transport stream (except for the PCR). When the item is deleted, the
item information is shaded in the hierarchy display.
Table 3-82 describes the text information and Table 3-83 describes the Bezel
menu commands for the NULL icon.
Table 3Ć82: NULL icon text descriptions
Parameter Description
PID Shows the PID value of the NULL.
Packet Rate Shows the average output rate of the NULL packet reference to the
output rate of the transport stream.
Table 3Ć83: NULL icon Bezel menu command (MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
NULL.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Adaptation Field Error
(ADFERR) Icon
NULL Icon
