Hierarchy Display
3Ć76
MTG100 & MTG300 MPEG Generator User Manual
Table 3-97 describes the text information for the Transport Stream (TS) icon
used with the S-TMCC and M-TMCC icons.
Table 3Ć97: Transport stream icon text descriptions
Parameter
Description
Relative TS
Shows the relative transport stream number.
TS_ID
Shows the ID number for the transport stream.
Contract Slot
Shows the number of contract slots.
Modulate/Slot(1)
Shows the number of slots (includes the number of invalid slots)
Table 3-98 describes the text information for the Non Transport Stream (Non TS)
icon.
Table 3Ć98: Non TS icon text descriptions
Parameter
Description
Filename
Shows the file name and path of the Non TS data.
Output Rate
Shows the output rate of the Non TS data.
File Length
Shows the file length of the Non TS data.
Table 3-99 describes the text information and Table 3-100 describes the Bezel
menu commands for the Service Information insertion file (INS_SI) icon.
Table 3Ć99: INS_SI icon text descriptions
Parameter
Description
PID
Shows the PID value of the packet.
Filename
Shows the name of the insertion file.
Table ID
Shows the table_id value of the table.
Packets
Shows the total number of packets in the section.
Section
Shows the current section mode: SINGLE or MULTI.
Start Time
Shows the start time when the data insertion is started.
Cont. Time
Shows the duration for the insertion.
Time System
Shows the standard time used to start the data insertion: Relative, TDT,
TOT, or STT.
File Interval
Shows the time interval between file insertions.
Packet Interval
Shows the interval between the packets when the inserted section file is
packetized.
Transport Stream (TS)
Icon
Non TS Icon
INS_SI Icon
